Real ranch infrastructure, deep rig extractions, solar windmill conversions, and custom freeze protection installations executed across West Texas by owner-operator Jesus Villarreal.
380 ft lift
🔍 View Full HD
Off-grid ranch windmill upgrade: Sturdy pole-mounted photovoltaic solar array powering a deep submersible Lorentz helical rotor pump, delivering continuous crystal-clear water to livestock troughs with zero utility power.
Wellhead Surface Completion
🔍 View Full HD
Poured reinforced concrete well pad, steel casing with vermin-proof sanitary seal flange, HydroPro captive-air pressure tank, Square D pressure switch, and unistrut electrical safety disconnect.
Surface Pressure Booster
🔍 View Full HD
Full ranch pressure distribution station featuring a 2,500-gallon black UV-resistant polyethylene storage tank, cast iron booster pump, and vertical captive-air tank feeding multiple ranch residential connections.
520 ft downhole extraction
🔍 View Full HD
Precision downhole fishing operation deploying hydraulic boom hoist rigging and heavy steel overshot spears to recover dropped tooling and separated drop pipe without losing the well.
Surface Electrical Center
🔍 View Full HD
Outdoor commercial NEMA pump control box, 230V heavy-duty safety disconnect switch, liquid-tight conduits, and surge arrestors mounted on heavy unistrut to withstand West Texas weather and lightning.
Remote Pasture Distribution
🔍 View Full HD
3,000-gallon green UV-rated water storage cistern built on a treated-timber skid foundation with booster pump, pressure tank, and ground-mount photovoltaic array for remote cattle pastures.
Surface Facility
🔍 View Full HD
All-weather corrugated steel pump house built on concrete slab to protect wellhead controls, pressure tanks, and booster pumps from freeze damage, sun exposure, and wildlife.
Sub-Surface Protection
🔍 View Full HD
Heavy-gauge welded steel valve vault with hinged locking lid and 2-inch pink rigid foam insulation protecting main pipeline brass ball valves from sub-freezing Texas winter freezes.
Water Quality & Sanitization
🔍 View Full HD
Precision Stenner peristaltic chemical metering pump mounted on dedicated solution tank with manifold injection check valve to neutralize iron bacteria, sulfur odor, and sanitize well water.
Livestock Water Supply
🔍 View Full HD
Heavy reinforced cast concrete drinking trough with protected float valve enclosure and steel riser frost-free hydrant, providing reliable water for cattle herds in dry pastures.
Solar Photovoltaic Lift
🔍 View Full HD
High-efficiency monocrystalline solar panels engineered on pump house roof mounts to eliminate long utility line extension costs, directly powering off-grid submersible pumping.
Gravity Distribution
🔍 View Full HD
Heavy-duty UV-stabilized black polyethylene storage tank elevated on a treated timber platform over fractured limestone terrain with brass bottom drain and poly delivery lines.
Indoor Wellhead Setup
🔍 View Full HD
Clean pump house installation featuring a HydroPro captive-air pressure tank, sanitary wellhead seal flange, Square D pressure switch, and brass pressure relief manifold.
High-Volume Booster
🔍 View Full HD
Heavy-duty cast iron booster pump assembly with dual yellow-handle brass isolation ball valves, pipe unions for fast servicing, and flexible electrical conduit connections.
Range Infrastructure
🔍 View Full HD
Heavy-gauge welded steel cylindrical sleeves with rebar lifting handles and hinged caps shielding buried poly waterline isolation valves from livestock trampling and brush fires.
Complete Turnkey System
🔍 View Full HD
End-to-end ranch water installation: Sanitary wellhead casing, poly waterline run, 2,500-gallon dedicated storage cistern, and concrete booster pad with pressure tank under open Texas skies.
From solar pump conversions to freeze-proof distribution vaults and emergency pump hoist service, Jesus Villarreal handles your project personally.
